M-Audio AIR 192/4

M-Audio AIR 192/4

• Mic Input 1 (balanced XLR)
  • FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.1 dB)
  • DYNAMIC RANGE 104 dB (A-weighted)
  • SIGNAL-TO-NOISE RATIO 104 dB (+1.0 dBu, A-weighted)
  • THD+N 0.003%
  • PREAMP EIN -128 dBu (max gain, 150 Ω source, A-weighted)
  • MAX INPUT LEVEL +1.5 dBu
  • GAIN RANGE 55 dB
• Line Input 1 (balanced 1/4" [6.35 mm] TRS)
  • FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.05 dB)
  • SIGNAL-TO-NOISE RATIO 101 dB (1 kHz, +4 dBu, A-weighted)
  • THD+N 0.003%
  • MAX INPUT LEVEL 16 dBu
  • GAIN RANGE 55 dB
• Inst Input 2 (unbalanced 1/4" [6.35 mm] TS)
  • FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.05 dB)
  • DYNAMIC RANGE 100 dB (A-weighted)
  • SIGNAL-TO-NOISE RATIO 102 dB (+ 4 dBu, A-weighted)
  • THD+N 0.004%
  • MAX INPUT LEVEL 6 dBu
  • INPUT IMPEDANCE 1 MΩ
  • GAIN RANGE 24 dB
• Main Outputs, L and R (balanced, differential 1/4" [6.35 mm] TRS)
  • FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.06 dB)
  • DYNAMIC RANGE / SIGNAL-TO-NOISE RATIO 102 dB (A-weighted)
  • THD+N 0.005%
  • MAX OUTPUT LEVEL +7 dBu (1 kHz, -1 dBFS)
• Headphone Output (impedance-balanced 1/4” [6.35 mm] TRS)
  • THD+N 0.005%
  • OUTPUT IMPEDANCE 10 Ω
• General
  • POWER USB-bus-powered
  • DIMENSIONS (WIDTH X DEPTH X HEIGHT) 8.0” x 6.0” x 2.76” (20.42 cm x 15.24 cm x 7.0 cm)
  • WEIGHT 2.0 lbs. 0.9 kg
